At a glance: 5–1,000 yd. integrated LRF | 60fps thermal imaging | 1024 × 768 OLED | IPX6 water resistance

New Rangefinding Capability

Thermal imaging takes much of the guesswork out of finding animals after sunset. By detecting differences in heat rather than relying on visible light, thermal optics make it possible to spot animals in darkness, even when they'd be difficult to pick out with conventional optics.

But finding an animal doesn't automatically tell you how far away it is.

That's where the Wraith 2's built-in laser rangefinder comes in.

Both Wraith 2 models feature a Class 1 laser rangefinder capable of measuring distances from 5 to 1,000 yards. The distance appears directly on the scope's display, so you won't need to put down your rifle to check a handheld device.

The rangefinder provides accuracy of ±1 yard at closer distances and ±0.5% beyond 200 yards.

For hog hunters watching an open field or predator hunters working along a distant tree line, knowing the actual distance can make a difference when evaluating a potential shot.

Vanadium Oxide: Why It Matters

Both Wraith 2 models use Vanadium Oxide (VOx) thermal sensors. That's a fancy name for something with a pretty straightforward job: detecting heat.

Vanadium Oxide is a heat-sensitive material used in thermal sensors called microbolometers. When infrared energy from an animal, person, or object reaches the sensor, it causes tiny changes in the material's electrical resistance. The scope translates those changes into the thermal image you see on the display.

So why Vanadium Oxide instead of something else?

Compared with another common thermal sensor material, amorphous silicon, VOx has traditionally been valued for its low electronic noise and excellent thermal sensitivity. That means it can help thermal sensors detect subtle temperature differences without introducing excessive image noise. The result can be cleaner thermal imagery, especially when the temperature contrast between an animal and its surroundings is small.

That's a meaningful advantage when you're scanning a field on a warm summer night. If the ground, vegetation, and animals are all relatively close in temperature, distinguishing one heat signature from another becomes more difficult. A sensitive, low-noise thermal sensor helps preserve those small differences so you have more information to work with.

VOx sensors also operate without a bulky cooling system, making them well suited for portable, battery-powered thermal optics. Their actual performance still depends on the sensor's design and electronics, but there's a reason Vanadium Oxide has become an established material in high-performance thermal imaging.

Both Wraith 2 models feature a 12-micron pixel pitch and a 60fps frame rate, providing smooth imagery when following moving animals. The main difference between them comes down to resolution, magnification, and detection range.

The Wraith 2 384 LRF (SM17006) is the practical choice for hunters who prefer a closer starting view and don't necessarily need the extra resolution of the 640. Its 384×288 sensor and 3× base magnification pair with a 35mm objective.

The Wraith 2 640 LRF (SM17013) packs nearly three times as many pixels into its 640×512 thermal image. Its 40mm objective lens and 2× base magnification provide a wider view for scanning, while the additional sensor resolution helps retain detail when examining distant heat signatures.

Both Wraiths use the same Vanadium Oxide sensor technology. The choice comes down to whether you prefer the 384's higher starting magnification or the 640's greater image detail and wider scanning view.

A Whole New Look for the Wraith

If you've used one of Sightmark's previous Wraith scopes, the Wraith 2 might make you do a double take.

The familiar Wraith design has been replaced by a completely different housing, giving the new thermal riflescopes a distinctly different profile. But the changes go beyond appearances.

For starters, the Wraith 2 features Picatinny accessory rails on the sides of its housing, allowing users to mount compatible external battery packs for extended operation.

And no, those rails aren't there for infrared illuminators. Unlike digital night vision, thermal imaging detects emitted heat rather than relying on reflected infrared illumination. Adding an IR illuminator won't help a thermal scope see better.

The Wraith 2 also introduces a redesigned battery compartment. Previous Wraith models used a push-button mechanism to access the battery. The Wraith 2 instead features a twist-to-unscrew battery cap, providing a more secure closure that helps protect the compartment against unwanted water intrusion.

The new housing carries an IPX6 water-resistance rating, meaning it's rated to withstand powerful water jets and is better equipped to handle heavy rain and wet conditions in the field. It doesn't make the optic submersible, but it's reassuring when the forecast says one thing and the weather decides otherwise.

Between its new form factor, accessory rails, and more secure battery compartment, the Wraith 2 represents a substantial physical redesign of the Wraith platform.

Built for More Than Just Spotting Heat

The Wraith 2 series has plenty of useful features beyond its thermal sensors and rangefinders.

• 1024 × 768 OLED Display: Both models give you a high-contrast view of the thermal image, with five color palettes: White Hot, Black Hot, Rainbow, Green Hot, and Iron Heat.
• 14 Reticle Options: Four first focal plane and ten second focal plane choices let you tailor the aiming display to your preferences.
• Record and Share: Onboard video recording, photo capture, and Wi-Fi connectivity let you document a hunt and share footage through the Sightmark app.
• Power for Longer Outings: An 18650 battery provides up to 4.5 hours of runtime in preview mode, with USB-C and external power support when you need more time.

Want to show your buddies what wandered into the field last night? You can document your hunt without adding a separate camera to your setup.

Both scopes feature durable aluminum alloy housings and an operating temperature range of -4°F to 122°F, making them suitable for everything from freezing winter mornings to sweltering summer nights.

Which Wraith 2 Is Right for You?

That depends on what matters most during your hunts.

The Wraith 2 384 LRF offers a higher 3× starting magnification and capable thermal imaging for hunters who want a practical balance of features and performance.

The Wraith 2 640 LRF prioritizes finer image detail and a wider scanning view, making it particularly appealing to hunters who regularly survey larger areas or want more information from distant heat signatures.

Either way, you're getting thermal imaging, an integrated laser rangefinder, a smooth 60fps image, and the ability to record what happens in front of you.

You're also getting an entirely redesigned Wraith, complete with a more secure battery compartment and additional mounting options for external power.
